DWL450
LHY
Material: | |
---|---|
Color: | |
Size: | |
Function: | |
use: | |
Availability: | |
Quantity: | |
Features
With double layer flexible fabric coated which is oil resistant, UV resistant and can be reusing for long time.
Can be quick deployed in a short time, especially for oil containment in offshore, inshore or in harbor.
Two people are needed to operate this mechanical recovery device.
Parameter | Overal height(mm) | Freeboard(mm) | Draft(mm) | Standard length per section(m) | Tensile strength(KN) | Ballast | Weight(kg/m) |
DWL450 | 450 | 150 | 300 | 5,15,20 | 20 | Block or chain | 3.1 |
DWL750 | 750 | 250 | 500 | 5,15,20 | 30 | Block or chain | 4.2 |
DWL900 | 900 | 300 | 600 | 5,15,20 | 40 | Block or chain | 5.2 |
DWL1100 | 1100 | 400 | 700 | 5,15,20 | 45 | Block or chain | 5.8 |
Features
With double layer flexible fabric coated which is oil resistant, UV resistant and can be reusing for long time.
Can be quick deployed in a short time, especially for oil containment in offshore, inshore or in harbor.
Two people are needed to operate this mechanical recovery device.
Parameter | Overal height(mm) | Freeboard(mm) | Draft(mm) | Standard length per section(m) | Tensile strength(KN) | Ballast | Weight(kg/m) |
DWL450 | 450 | 150 | 300 | 5,15,20 | 20 | Block or chain | 3.1 |
DWL750 | 750 | 250 | 500 | 5,15,20 | 30 | Block or chain | 4.2 |
DWL900 | 900 | 300 | 600 | 5,15,20 | 40 | Block or chain | 5.2 |
DWL1100 | 1100 | 400 | 700 | 5,15,20 | 45 | Block or chain | 5.8 |
Technical Data
Specifications | KW800 | KW Â 900 | KW Â 1000 | KW Â 1200 | KW Â 1600 |
Overall  Height(mm) | 800 | 900 | 1000 | 1200 | 1600 |
Freeboard(mm) | 270 | 320 | 340 | 380 | 530 |
Draft(mm) | 390 | 460 | 540 | 580 | 780 |
Section  Length(m) | 100 | ||||
Tensile  Strength(KN) | 60 | 65 | 70 | 80 | 100 |
Laying  Speed(m/s) | 40 | 40 | 40 | 40 | 40 |
Wave  Height (m) | 0.8 | 1.2 | 1.2 | 1.5 | 2 |
Wind  Speed(m/s) | 6 | 6 | 10 | 12 | 15 |
.Note: This information is provided for reference, we reserve the rights to modify in transaction
Technical Data
Specifications | KW800 | KW Â 900 | KW Â 1000 | KW Â 1200 | KW Â 1600 |
Overall  Height(mm) | 800 | 900 | 1000 | 1200 | 1600 |
Freeboard(mm) | 270 | 320 | 340 | 380 | 530 |
Draft(mm) | 390 | 460 | 540 | 580 | 780 |
Section  Length(m) | 100 | ||||
Tensile  Strength(KN) | 60 | 65 | 70 | 80 | 100 |
Laying  Speed(m/s) | 40 | 40 | 40 | 40 | 40 |
Wave  Height (m) | 0.8 | 1.2 | 1.2 | 1.5 | 2 |
Wind  Speed(m/s) | 6 | 6 | 10 | 12 | 15 |
.Note: This information is provided for reference, we reserve the rights to modify in transaction
