Features
With double strength, durable PVC-coated polyester fabric, bright orange.
As the ropes, ballast and strengthen fabric with good buoyancy which helps the skirt is oil and chemical resistant in water.
The boom is made from cylindrical polyethylene foam.
20m section length. Marine grade extruded aluminum ASTM style end connectors which can be easily joined without tools.
Features
With double strength, durable PVC-coated polyester fabric, bright orange.
As the ropes, ballast and strengthen fabric with good buoyancy which helps the skirt is oil and chemical resistant in water.
The boom is made from cylindrical polyethylene foam.
20m section length. Marine grade extruded aluminum ASTM style end connectors which can be easily joined without tools.
Performance
Specifications | WGV600 | WGV 750 | WGV 900 | WGV 1100 | WGV1500 | |
Overall Height (mm) | 600 | 750 | 900 | 1100 | 1500 | |
Freeboard (mm) | 130 | 260 | 300 | 360 | 500 | |
Draft (mm) | 380 | 390 | 480 | 560 | 750 | |
Section Length (m) | 20/30 | |||||
Tensile Strength (KN) | 20 | 30 | 50 | 850 | 120 | |
Wave Height Resistance | 0.3m | 0.5m | 1m | 1.5m | 2m | |
Wind Speed Resistance | 8 m/s | 10 m/s | 15 m/s | 20 m/s | 20 m/s | |
Current Resistance (Kn) | 1 | 1.5 | 1.5 | 2 | 3 | |
Packing Dimension (20m) | 1*1*0.6 | 0.8*1*1 | 1*1.1*1.2 | 1.3*1.6*1.5 | 1.5*1.9*1.8 |
Note: This information is provided for reference, we reserve the rights to modify in transaction.
