Features
Soft floating dam
Physical technologies (adjustable according to seasons, water temperature and growth period and bloom movement of blue algae for algae isolation) It combined physical intercept with ecological control to isolate blue algae and suspensions from spreading so that can control water pollution to protect and improve water quality.
Controllable river diversion and precaution against typhoon section is available.
a. Controllable algae function makes it available to contain, dredge blue algae and changing the direction of a stream of water. It can decrease the difficulties of control and also save the cost of contain pollution.
b.With river diversion section which support to assemble and disassemble section accordingly in different hydrological dynamics, direction and power of wind.
c. Controllable navigation passes sections which allow house boats and small ships came in and go out freely.
Technology Maturity of silt curtain:
Design the most suitable proposal for customers’ project correspondingly is available due to different current and wind speed. With fast after-service, instruction of deployment, maintenance and all round guidance.
With solid flotation double side PVC or rubber boom which have smooth surface can be easy to be cleaned also oil resistant and UV resistant for permanent deployment. Replaceable ballast chain can makes the boom with good stability in water. It also have good buoyancy and float weight ratio for contain suspensions.
Technical Data
Specifications | FDXL700 | FDXL900 | FDXL1100 |
Overall Height(mm) | 700 | 900 | 1100 |
Free board(mm) | 260 | 300 | 360 |
Depth of Curtain | Depending on water level or suspended matter distribution in the water layer | ||
size(mm) | 0.2-5 | ||
Draft(mm) | 380 | 480 | 560 |
Section Length(m) | 20M | ||
Tensile Strength(KN) | 40 | 65 | 85 |
Float Weight Ratio | 5.6 | 6.2 | 5.5 |
Wave Resistant(m) | 1 | 1.8 | 2 |
Wind Resistant(m/s) | 15 | 18 | 20 |
Currant Resistant(Kn) | 1.5 | 2 | 2.5 |
Packing Dimension(m) | 1.2X1X1 | 1.4X1.5X1.2 | 1.4X1.7X1.4 |
Note: This information is provided for reference, we reserve the rights to modify in transaction
.
